Additional data
|
| Rated input power |
600 W |
| Weight |
1.8 kg |
| No-load speed, 1st gear |
0 ‰ÛÒ 2,800 rpm |
| Power output |
301 W |
| Tool dimensions (width) |
266 mm |
| Tool dimensions (length) |
180 mm |
| Impact rate at no-load speed |
0 ‰ÛÒ 44,800 bpm |
| Rated torque |
1.8 Nm |
| Drill spindle connecting thread |
1/2"-20 UNF |
| Chuck capacity, min./max. |
1.5 ‰ÛÒ 13 mm |
| Tool dimensions (height) |
180 mm |
Drilling range
|
| Drilling diameter in wood |
25 mm |
| Drilling diameter in steel |
10 mm |
| Drilling diameter in masonry |
15 mm |
Total vibration values (Drilling in metal)
|
| Vibration emission value ah |
3 m/så_ |
| Uncertainty K |
1.5 m/så_ |
Total vibration values (Impact drilling in concrete)
|
| Vibration emission value ah |
26 m/så_ |
| Uncertainty K |
3 m/så_ |
Total vibration values (Screwdriving)
|
| Vibration emission value ah |
2.5 m/så_ |
| Uncertainty K |
1.5 m/så_ |
Noise/vibration information
|
| Sound pressure level |
97 dB(A) |
| Sound power level |
108 dB(A) |
| Uncertainty K |
5 dB |
Drilling in metal
|
| Vibration emission value ah |
3 m/så_ |
| Uncertainty K |
1.5 m/så_ |
Impact drilling in concrete
|
| Vibration emission value ah |
26 m/så_ |
| Uncertainty K |
3 m/så_ |
Screwdriving
|
| Vibration emission value ah |
2.5 m/så_ |
| Uncertainty K |
1.5 m/så_ |
The A-rated noise level of the power tool is typically as follows: Sound pressure level 97 dB(A); Sound power level 108 dB(A). Uncertainty K= 5 dB.
